GRACO 25N635 – G-FORCE II 3230 HA-DD Pressure Washer, 3200 PSI, 3 GPM w/ Honda Engine & AR Pump

GRACO 25N635 – G-FORCE II 3230 HA-DD Pressure Washer, 3200 PSI, 3 GPM w/ Honda Engine & AR Pump

Although identical in size and function as the MP20, the MP40 has double the output and can pump up to 200 bags per hour of selfleveling underlayment. The larger motor and pump make the MP40 an excellent fit for contractors looking for a high production solution.

Ideal for self-leveling underlayment, non-shrink grout and pre-blended toppings

Compact, easy to maneuver

Easy to operate with variable speed control

425 PSI (29 bar) pumping pressure

Vertical pumping distance: 60 feet (18 m)

Horizontal pumping distance: 200 feet (61 m)

Rugged hopper with bag breaker holds six 50-lb (23 kg) bags

Power MP40: 230V, 30A, 3-ph

Output MP40: up to 50 lpm (100 cu ft/hr)

Additional Specifications

Max Working Pressure: 3200 PSI (22.1 MPa, 221 Bar)

Flow Rate: 3.0 GPM

Crankcase Oil Capacity: 16.0 oz (0.47 L)

Engine Brand	Honda
Engine Model	GX270
Fuel Tank Capacity (qt)	6.4
Hose Inlet Diameter (in)	3/8
Hose Length (ft)	50
Includes	Professional-Grade Pressure Washer Spray Gun with Quick Connects, 36 in Pressure Washer Wand with Quick Connect, 3/8 in x 50 ft Non-Marking Pressure Washer Hose, 4 ft Chemical Injector Hose with Strainer, 0° Red Pressure Washer Tip, 15° Yellow Pressure Washer Tip, 25° Green Pressure Washer Tip, Black Chemical Pressure Washer Tip
Maximum Flow Rate (GPM)	3
Maximum Fluid Pressure (psi)	3200
Maximum Operating Temperature (°F)	145
Maximum Working Pressure (MPa)	22.1
Maximum Working Pressure (psi)	3200
Model	G-Force II
Motor Drive Type	Direct Drive
Pump Brand	AR
Pump Type	Triplex Plunger
Recommended Weekly Usage (Hours)	10-20
Series	3230
Type	Gas Pressure Washer
Weight (lb)	76

Compatible Equipment

G-FORCE II pressure washer series

Direct-Drive pressure washer system

GX270 engine (part 803900 – Engine, Gas, 9.0 HP, Hnda, 49 State), AR RSV series pump (part 177103), Various nozzles, hoses, and accessories listed in parts breakdown, Pump 17Z102

Related Parts

25N634 – G-FORCE II 3325 HA-DD Pressure Washer, 3300 PSI, 2.5 GPM w/ Honda Engine & AR Pump

25N638

25N639 – G-Force II 3230 HA-DD Pressure Washer, AR Brass Triplex pump, 3200 PSI

25N636 – G-FORCE II 4240 KA-DD Pressure Washer, 4200 PSI, 4 GPM w/ Kohler Engine & AR Pump

25N640

25N637 – G-FORCE II 4240 HA-DD Pressure Washer, 4200 PSI, 4 GPM w/ Honda Engine & AR Pump

25N641

25N677 – G-FORCE II 4040 HG-DD Pressure Washer, 4000 PSI, 4 GPM w/ Honda Engine & GP Pump

25N681, 25N677K

This is a 3200 PSI pressure washer model with Honda engine, AR pump, and direct drive system. Part of the G-FORCE II series. 25N635 appears as a model number throughout the parts list indicating compatibility with various components including engine 803900 (GX270), pump 177103 (AR RSV series), wheels, handles, hoses, nozzles, unloader, injector, thermal valve, and various labels. This appears to be part of a family of direct-drive pressure washer models. 25N635 is listed as one of the compatible models for the pump assemblies shown. The crankcase oil capacity specification applies to the pump system used with this model.

Reference Manuals

3A6588 (Page 2) Pressure Washers, Operation, Repair, Parts
