GRACO 17G179 – Magnum ProX19 Electric TrueAirless Sprayer, Stand
Professional electric TrueAirless paint sprayer featuring ProX stainless steel piston pump for greater reliability and long life, with ProXChange pump system that eliminates downtime through quick, no-tools pump replacement on-the-job. Designed for contractors and serious DIYers who need reliable performance and easy maintenance.
GRACO 17G179 Magnum ProX19 Electric TrueAirless Sprayer, Stand The ProX19 airless sprayer is the solution for property maintenance pros, remodelers and general contractors with fast-paced projects of any kind. Spray thicker materials with larger tip size capability and avoid downtime with the ability to quickly swap the pump on the job without tools.
ProX Stainless Steel Piston Pump – For greater reliability and long life
ProXChange Pump System – Eliminates downtime with quick, no-tools pump replacement on-the-job
DC Motor – Supports longer extension cords and up to 150 feet of airless hose
PushPrime – Fast and reliable start-up every time
SG3 Metal Spray Gun – Premium spray gun with hose swivel making it easy to manage longer hose lengths
TrueAirless Spray Tip with SoftSpray Technology – greater control and less overspray with a wide range of coatings
Compact Design – Move paint and sprayer around job site
Adjustable Pressure – Easy control of paint flow
InstaClean Pump Filter – Added pump filtration reduces tip clogs from debris in the paint
Power Flush Adapter – Connects to garden hose for fast and easy cleanup
Specifications
Additional Specifications
Flow Rate: 0.34 gpm
Material: Stainless Steel Piston Pump
Sprayer Weight: 38 lbs
Max Tip Size: 0.19
Specifications
Amperage (A)
8
Compatible Tip Size (in)
0.009, 0.011, 0.013, 0.015, 0.017, 0.019
Engine Size (HP)
0.875
Fluid Outlet Size (in)
1/4
Fluid Outlet Thread Type
NPSM
Frame Configuration
Stand
Includes
SG3 Spray Gun, TrueAirless 515 Spray Tip, Spray Tip Guard, 1/4 in x 50 ft DuraFlex Hose, Pump Armor Storage Fluid (8 oz), Quick Start-Up Guide
Inlet Paint Strainer
35 Mesh Stainless Steel Screen
Maximum Flow Rate (GPM)
0.38
Maximum Hose Length (ft)
150
Maximum Tip Size (in)
0.019
Maximum Tip Size 1 Gun (in)
0.019
Maximum Working Pressure (MPa)
20.7
Maximum Working Pressure (psi)
3000
Minimum Generator Power (W)
2500
Model
Magnum
Motor Type
DC
Number of Guns
1
Outlet Paint Filter
InstaClean
Overall Height (in)
21.2
Overall Length (in)
15.1
Overall Width (in)
13.2
Phase
1
Power Rating (HP)
0.875
Power Rating (W)
652.5
Power Rating (kW)
0.65
Power Source
Electric
Pressure Control Type
Adjustable
Pump Mount Type
ProXchange
Pump Rod Type
Stainless Steel
Pump Sleeve Material
Stainless Steel
Pump Type
Piston
Recommended Annual Usage (gal)
500
Series
ProX19
Standards Met
Certified to CAN/CSA C22.2 No.68, Conforms to UL1450, ETL Listed, NMX-J-521/1, NOM-003-SCFI
PushPrime – helps reduce priming problems due to debris/poor cleaning
Filter – filters debris in paint to reduce tip plugs and improve finish
Pump Filter – extra filtration to improve finish
On-the-job Pump Repair
Power Flush – connect to garden hose for fast clean-up
Applications
Medium to large painting projects
Professional-grade applications for serious DIYers
Projects requiring up to 300 gallons annual usage
Professional painting contractors
Serious DIY projects
Medium-duty painting applications
Compatible Equipment
50 ft x 1/4 in paint hose
515 spray tip
Metal SG3 spray gun
Up to 150 ft airless hose
Garden hose connection for cleanup
Related Parts
17G180 – Magnum ProX19 Handheld version
17G181 – Magnum ProX21
17G163 – Magnum ProX21, Part of Magnum ProX series, Pro Series family
262800 – Magnum X5
262805 – Magnum X7
17G178 – Magnum ProX17
Kit Contents
ProX Power Piston Pump
Metal SG3 Spray Gun
515 Spray Tip
50 ft x 1/4 in Paint Hose
50 ft DuraFlex Hose
SG3 Metal Spray Gun
515 Reverse-A-Clean Spray Tip
Pump Armor Storage Fluid
Quick Start-Up Guide
Metal SG2 spray gun
This is the cart/stand version of the ProX19, as opposed to the handheld model 17G180. Designed for users who need more capacity and mobility than smaller sprayers. One year warranty. Made in USA with global components. Annual usage is a general guideline to help with product selection only. With good care and routine maintenance your sprayer will last for years. Part of GRACO’s Magnum Pro series of professional electric airless sprayers. Stand-mounted configuration provides enhanced stability compared to handheld models.
Reference Manuals
344066 (Page 10) Magnum & TrueCoat 360 Product Guide
