FILL-RITE TN620ALQ – 23-151 LPM 3-Digit Mechanical Fuel Transfer Meter

TN620ALQ 23-151 Lpm 3-Digit Mechanical Fuel Transfer Meter

The TN620ALQ is a high pressure, high viscosity, and highly accurate 3-digit mechanical fuel transfer meter. This meter is equipped with NPT threads and is designed to register 23-151 liters per minute at +/- 2% accuracy. This model does not include additional accessories.

Features:

Reliable Technology dependable positive displacement, nutating disc technology provides trusted accuracy, every season, every year

Numerous Applications Ideal for the most demanding applications handling Arline Lavatory Solvents (ALS), biodiesel, fuel oil No. 2, and non-potable water

Durable Construction built to last with an anodized aluminum case and resin metering chamber, designed to withstand the toughest environments

Versatile Compatibility ideal for transferring heavy oils or high viscosity liquids quickly and safely

Specifications:

Catalog	1″ NPT, Liters, Nickel-Plated, Airline Lavatory Service & Solvents
Technology	Nutating Disc
Flowrate Range	19-76 LPM
Operating Temperature Range	-15 – 150°F / -26 – 66°C
Accuracy (+/- %)	0.01
Repeatibility (+/- %)	0.0038
Display Digits	3
Inlet Size (in)	1 “
Inlet Thread	NPT
Outlet Size (in)	1 “
Outlet Thread	NPT
Compatible Fluids	Lavatory Water
Package Dimensions(in)	10.5 x 7.38 x 7.25
Gross Weight (lbs) (from SAP)	4.900 lbs
Certifications
Warranty	2 Years
UPC	89404197141
